Garbage Truck - ERNHI 125

Overview

For the developed traffic system city, equipping our 14.0 m³ garbage is a reasonable upgrading to transfer solid waste. By many years experiences, SAMCO designed and calculated the maximum compatibly rate between HINO FG8JJSB cab chassis and our special system to ensure the investment of customers. Besides, with the garbage tailgate cover equipped, which will preserve the hygiene and ensure the urban aesthetics.

  • Chassis: Hino FG8JJ7A
  • Payload: 6,600 kg
  • Gross vehicle weight: 16,000 kg
  • Volume: 14.0 m³
  • Standard Emission: Euro 4
Brochure download
<p>Garbage truck, Hino, Garbage tailgate cover, Garbage loading structure</p>

Technical Specifications

Cab chassis Hino FG8JJ7A
Engine J08E-WE
Max. output 191 / 2,500 kW/rpm
Displacement 7,684 cc
Overall Dimensions (L x W x H) 8,300 x 2,500 x 3,100 mm
Wheelbase 4,280 mm
G.V.W 16,000 kg
Payload 6,200 kg
Kerb mass 9,205
Tank Volume: 14.0 m³
Body profile: Curve wall, curve top
Tank material: SPA-H steel, Japan
Compacting force 19,000 kgf
Hydraulic equipments Imported from Europe
Operating accelerator: Uninterrupted electro-pneumatic accelerator
Options Garbage Tailgate Cover
240 littre / 660 littre garbage bin clipper
Two-arms garbage loading structure
Standard garbage loading structure combined with removable garbage bulldoze
Operating accelerator Uninterrupted eletric accelerator
Garbage loading control by automatic mechanism - Clip bin
- Turn up bin into the trough
- Turn bin down
- Release bin
Garbage compacting control by automatic mechanism in two modes - Continuous automatic operation
- Manual operation
Garbage ejecting control by manual control - Opening locks and lifting tailgate
- Ejecting garbage
- Moving the ejecting plate pack
- Lowering and locking the tailgate
Tank Blue, Green, Orange, White, or design marquette base on customer's request
Product policy In accordance with our policy of constant product improvement, all specifications could be changed without notice.
The Garbage Tailgate Cover for standard garbage truck, bulldozing garbage truck, two-arms loading garbage truck is protected for industrial design under Vietnamese Law of Intellectual Property. All copy without SAMCO authorizing is unlawful.
